| Brand Name: | Bioclean |
| Model Number: | ZBJ4250DBEV15 |
| MOQ: | 1 |
| Price: | 70000 |
| Payment Terms: | T/T |
| Supply Ability: | 500unit/year |
Product Description
| English Translation | Technical Data | English Translation | Technical Data |
|---|---|---|---|
| Gross Vehicle Weight (GVW) | 25000 kg | Load Utilization Coefficient | — |
| Curb Weight | 14560 kg | Rated Payload | (kg) |
| Towed Trailer Mass | 34310 kg | Fifth Wheel Load Rating | 10310 kg |
| Cab | — | Front Seat Passengers | 2 persons |
| Rated Passenger Capacity | (persons) | Anti-lock Braking System (ABS) | Equipped |
| Approach Angle / Departure Angle | 13° / 20° | Front Overhang / Rear Overhang | 1480 mm / 810 mm |
| Axle Load | 7000 / 18000 kg (dual axle group) | Wheelbase | 3800 + 1350 mm |
| Number of Axles | 3 | Maximum Speed | 89 km/h |
| Fuel Consumption | — | Leaf Spring Configuration | 2/3, 3/4, 4/3, 5/2, 2/2, 2/4, 3/12, 3/13, 9/13 |
| Number of Tires | 10 units | Tire Specification | 295/80R22.5 18PR, 12R22.5 18PR, 12.00R20 16PR / 12.00R20 18PR |
| Front Wheel Track | 2020 mm, 2040 mm, 2070 mm | Rear Wheel Track | 1860/1860 mm, 1880/1880 mm |
Specification
Optional equipment includes:
Cabs of different heights and appearances;
Front fascia, side trim panels, bumpers and front lamps with different appearances;
Decorative decals;
Step side skirts, roof-mounted fairings, and rear-mounted deflectors;
The "Dongfeng Commercial Vehicle" logo on the cab roof can be omitted, and the roof fairing and rear deflector can also be omitted;
Cameras and radar sensors at the front of the cab;
Brake chambers with different installation positions;
Motors with different suspension structures;
Air reservoirs with different shapes;
Charging port on the right side.
EBS Model and Manufacturer: EBS5
This EBS system includes all functions of ABS.
The vehicle is equipped with a tachograph with satellite positioning function.
Battery Type / Energy Storage Cell and Assembly Manufacturer:
Lithium Iron Phosphate (LFP) Battery / CATL / CATL.
This vehicle model can optionally be fitted with an on-board ETC (Electronic Toll Collection) device.
