| Brand Name: | Bioclean |
| Model Number: | ZBJ5323GYYLC6 |
| MOQ: | 1 |
| Price: | 30000 |
| Payment Terms: | L/C,D/A,D/P,T/T |
| Supply Ability: | 500unit/year |
|
FAW J6P 8X4 Fuel Tank Truck LHD/RHD
|
|
|
Model
|
ZBJ5323GYYLC6
|
|
Cabin
|
FAW J6P high‑roof hazardous‑goods cab, power window, air‑conditioner
|
|
Engine
|
CA6DK1‑32E61, 320HP (239 kW), displacement 7146 ml
|
|
Transmission
|
CA9TB160 M manual gearbox
|
|
Suspension
|
Rear axle air suspension
|
|
Brake System
|
Front disc brake; EBS; ESC anti‑roll‑over; LDW lane departure warning; FCW forward collision warning
|
|
Tank Material
|
5083 aluminum alloy; shell & head & anti‑surge baffle thickness: 6 mm
|
|
Tire
|
12R22.5‑18PR radial tyre, aluminum rims
|
|
Oil tank
|
420L
|
|
Tank volume
|
25.6 m³; Effective working volume: 24.82 m³
|
|
Overall dimension
|
11730 × 2550 × 3550 mm
|
|
Color
|
For option
|
Specification
| Item | Specification |
|---|---|
| Cab | FAW J6P high‑roof hazardous‑goods cab, power window, air‑conditioner |
| Engine Option 1 | CA6DK1‑32E61, 320HP (239 kW), displacement 7146 ml |
| Engine Option 2 | CA6DL6‑36E6, 360HP (268 kW) |
| Transmission | CA9TB160 M manual gearbox |
| Suspension | Rear axle air suspension |
| Brake System | Front disc brake; EBS; ESC anti‑roll‑over; LDW lane departure warning; FCW forward collision warning |
| Safety Device | Tyre‑burst emergency protection for steering axle; front‑mounted exhaust pipe; speed limiter; satellite GPS tachograph; 300L aluminum fuel tank |
Tank Body (Superstructure)
| Item | Specification |
|---|---|
| Tank Material | 5083 aluminum alloy; shell & head & anti‑surge baffle thickness: 6 mm |
| Nominal Tank Volume | 25.6 m³; Effective working volume: 24.82 m³ |
| Compartments | Single compartment (multi‑compartment optional) |
| Top Fittings | 2 sets of Euro‑standard manhole covers, breathing valve |
| Bottom Valve | Intelligent emergency shut‑off bottom valve (remote‑control available) |
| Bottom‑loading System | Unloading valve, vapour recovery port, overfill‑protection probe, static‑earth‑reel |
| Oil Pump | Model 80‑60 pump, pump‑in & pump‑out function |
| Accessories | Aluminum anti‑surge baffles, side ladder, handrail, tool‑box, side & rear protection, fire‑extinguishers, static grounding strap, hazard marking |
| Transport Medium | Gasoline, diesel, kerosene (Class‑3 flammable liquid) |
Chassis Configuration
