| Brand Name: | BIOCLEAN |
| Model Number: | BCCVB-FG |
| MOQ: | 1 |
| Price: | 6000-12000 USD |
| Payment Terms: | T/T,Western Union,MoneyGram |
| Supply Ability: | 10000 Units per year |
| 2 Axles Van Semi Trailer | 3 Axles Van Semi Trailer | 4 Axles Van Semi Trailer |
| Application:Food/Cargo Loading | ||
| Loading Capacity:20-50 Tons | Loading Capacity:30-60 Tons | Loading Capacity:60-100 Tons |
| L*W*H:13000mm*2550mm*2400mm | ||
| Door Position:Multi-Choice | ||
| Door opening style:Multi-Choice | ||
| Box Plate Thickness:0.9mm | ||
| OEM/ODM:Available | ||
| Tandem Style:Available | ||
| SKD/CKD Cooperation:Available | ||
| 2 Axles Van Semi Trailer | 3 Axles Van Semi Trailer | 4 Axles Van Semi Trailer |
| Main Beam Material | ||
| Height: 500mm | Height: 500mm | Height: 500mm |
| Upper Plate: 12mm | Upper Plate: 14mm | Upper Plate: 16mm |
| Middle Plate: 6mm | Middle Plate: 8mm | Middle Plate: 10mm |
| Lower Plate: 14mm | Lower Plate: 16mm | Lower Plate: 18mm |
| Axles:2*13T/16T FUWA/BPW | Axles:3*13T/16T FUWA/BPW | Axles:4*13T/16T FUWA/BPW |
| Tire:11.00R20/12R22.5*8 pieces, Linglong/Triangle/Double-Coin/Bridgestone | Tire:11.00R20/12R22.5*12 pieces, Linglong/Triangle/Double-Coin/Bridgestone | Tire:11.00R20/12R22.5*16 pieces, Linglong/Triangle/Double-Coin/Bridgestone |
| Rim:9.0/8.0*8 pieces, steel/aluminum | Rim:9.0/8.0*12 pieces, steel/aluminum | Rim:9.0/8.0*16 pieces, steel/aluminum |
| Suspension:Mechanical/ Air | Suspension:Mechanical/ Air | Suspension:Mechanical/ Air |
| Leaf Spring:90mm*13/16mm*10 pieces | Leaf Spring:90mm*13/16mm*10 pieces | Leaf Spring:90mm*13/16mm*10 pieces |
| Landing Gear:Jost 28T two-speed | Landing Gear:Jost 28T two-speed | Landing Gear:Jost 28T two-speed |
| King Pin:Jost 2''(50#)/3.5''(90#) changeable | King Pin:Jost 2''(50#)/3.5''(90#) changeable | King Pin:Jost 2''(50#)/3.5''(90#) changeable |
| Tool Box:steel/aluminum | Tool Box:steel/aluminum | Tool Box:steel/aluminum |
