Product descriptions

• 18m³ Mobile Waste Compaction System: High-Efficiency & Economical Sanitation Solution




  Designed for large cities, provincial waste transfer hubs, mega industrial parks, and key BRI infrastructure projects, this 18m³ mobile compactor combines generous capacity with advanced compression technology—meeting mid-to-large-scale waste management needs while boosting efficiency and reducing long-term costs.




  Core Advantages: Efficiency & Economy




  Operational Efficiency




  • Strong Throughput: 80-100 TPD, serving 100,000-150,000 residents or large industrial zones. "Non-stop compaction + fast transit" design improves efficiency by 40% vs. 15m³ models.
  • Fast Compaction: Dual synchronized high-pressure rams (180-220 tons force) complete a cycle in 95-130 seconds, ensuring uninterrupted processing during peak hours.
  • Streamlined Loading: Airtight bins load onto trucks in ≤65 seconds, enhancing transfer efficiency by 29% vs. traditional units.
  • Superior Compression: 3.9:1 ratio (1.08 t/m³ density), drastically reducing waste transport volume.

  Cost Savings

  • Lower Transport Costs: 65% fewer truck trips vs. low-capacity equipment, cutting annual fuel, labor, and landfill fees by 32%.
  • Energy Efficiency: Optimized hydraulic system with energy recuperation uses 22-30 kW/h per cycle—19% lower than standard mid-to-large capacity models.
  • Minimal Upkeep: Wear-resistant parts, modular design, and anti-corrosion coating extend maintenance intervals to 5.5 months, slashing annual costs by 24%.
  • Fast ROI: 3.5-4.5 year payback period, ideal for municipal projects, mid-to-large PPPs, and industrial waste collaborations in emerging markets.

  Working Principle

  1. Waste Intake: Oversized auto-hopper (or optional full-automatic conveyor) with smart speed-adjustable anti-clog system ensures smooth flow of mixed/bulky waste—no manual support.
  2. Horizontal Compression: Dual synchronized rams apply uniform high pressure; adaptive control adjusts force by waste volume to optimize efficiency.
  3. Airtight Transit: Compacted waste is pushed into the 18m³ sealed bin with hydraulic locking. Quick-release latches enable fast truck loading for continuous operation.
  4. Eco-Compliant Operation: Compression sewage is collected in a closed tank (meets international discharge standards); dual-stage deodorization eliminates odors and bacteria, complying with BRI and global regulations.

  Ideal Applications




  Large/medium cities, provincial transfer stations, mega residential/commercial complexes, industrial parks, and key BRI waste projects (e.g., Philippines, Turkey, Kenya, Vietnam)—replacing outdated open sites or low-efficiency mid-to-large capacity equipment.




  Why Choose This Model?




  A premium mid-to-large capacity solution, it balances robust processing power, efficiency, and cost control. Its high compression ratio and fast cycle time maximize waste reduction, while energy-saving features and extended maintenance intervals minimize long-term costs. Built with durable high-tensile steel to withstand harsh climates and heavy use, it requires minimal specialized training—making it the top choice for municipal governments, private operators, and international PPPs, delivering reliable performance, tangible savings, and sustainable value.




  Product Specification







  Parameter	Specification
  Rated Volume	18 m³
  Daily Processing Capacity	80-100 TPD
  Compression Ratio	3.9:1
  Compacted Waste Density	1.08 t/m³
  Compaction Force	180-220 tons
  Compression Cycle Time	95-130 seconds
  Energy Consumption per Cycle	22-30 kW/h
  Maintenance Interval	5.5 months
  Bin Loading Time	≤65 seconds/bin
  Overall Dimensions (L×W×H)	6800×2500×2700 mm
  Net Weight	5.8-6.5 tons
  Gross Weight (Full Load)	22-24 tons
  Main Structure Material	Q355 high-tensile steel (side plate: 5mm; base plate: 7mm)
  Feed Hopper Capacity	5.2 m³
  Hydraulic System Working Pressure	24 MPa
  Sewage Treatment	Closed-loop collection + filtration system
  Deodorization System	Activated carbon + spray dual-stage deodorization
  Operating Temperature Range	-9℃ to 52℃
  Noise Level	≤71 dB
  Safety Standards	ISO 14121, CE, EN 840 certification
  Payback Period	3.5-4.5 years
