| Brand Name: | Bioclean |
| MOQ: | 1pc |
| Price: | $2000-$9999 |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 2000pcs/year |
|
Component Name
|
Serial Number
|
project
|
Parameter values/specifications
|
|
Complete vehicle
|
1
|
Model
|
ZBJ-G22D
|
|
2
|
Sweeping width
|
2200mm
|
|
|
3
|
Main brush width
|
800mm
|
|
|
4
|
working efficiency
|
10000-16000m²/h
|
|
|
5
|
working hours
|
3-8h
|
|
|
6
|
Dustbin capacity
|
200L
|
|
|
7
|
Side-brush diameter
|
Front 600mmMiddle 600mm
|
|
|
8
|
Walking speed
|
0-14km/h
|
|
|
9
|
Overall dimensions
|
2600*2200*2350mm
|
|
|
10
|
water tank
|
200L
|
|
|
11
|
Vacuum filtration area
|
12m²
|
|
|
12
|
Tyre type
|
Front 400-8, rear 400-8 solid tyre
|
|
|
13
|
control mode
|
Intelligent control system (timed dust shaking function)
|
|
|
Warning lights
|
1
|
Headlight
|
Four way LED headlights
|
|
2
|
tail light
|
Steering+braking+driving integrated taillights
|
|
|
3
|
Alarm lamp
|
Top operation warning light
|
|
|
4
|
HD reverse camera
|
||
|
Storage battery
|
1
|
Type
|
Lead acid maintenance free (optional with lithium battery)
|
|
2
|
Battery capacity
|
Standard 48V-150AH*6/200AH*8/240AH*8lead-acid battery
|
|
|
Electrical machinery
|
1
|
Walking motor
|
1000W intelligent gear change
|
|
2
|
Rolling brush motor
|
1000W
|
|
|
3
|
side-brush motor
|
4*100W
|
|
|
4
|
Motor voltage
|
48V
|
|
|
High pressure water pump
|
1
|
High pressure fog-cannon range
|
6-10m
|
|
2
|
High pressure water-gun range
|
10-18m
|
|
|
3
|
power
|
1500W
|
|
|
4
|
Pressure range
|
0-13Mpa
|
|
|
5
|
Max rate of flow
|
11L/min
|
|
|
Rearview mirror
|
1
|
model
|
Dedicated for sweeping vehicles
|
