| Brand Name: | Bioclean |
| MOQ: | 1pc |
| Price: | $2000-$9999 |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 2000pcs/year |
| Component Name | Serial Number | project | Parameter values/specifications |
|---|---|---|---|
| Complete vehicle | 1 | Model | ZBJ-G22D |
| 2 | Sweeping width | 2200mm | |
| 3 | Main brush width | 800mm | |
| 4 | working efficiency | 10000-16000m²/h | |
| 5 | working hours | 3-8h | |
| 6 | Dustbin capacity | 200L | |
| 7 | Side-brush diameter | Front 600mmMiddle 600mm | |
| 8 | Walking speed | 0-14km/h | |
| 9 | Overall dimensions | 2600*2200*2350mm | |
| 10 | water tank | 200L | |
| 11 | Vacuum filtration area | 12m² | |
| 12 | Tyre type | Front 400-8, rear 400-8 solid tyre | |
| 13 | control mode | Intelligent control system (timed dust shaking function) | |
| Warning lights | 1 | Headlight | Four way LED headlights |
| 2 | tail light | Steering+braking+driving integrated taillights | |
| 3 | Alarm lamp | Top operation warning light | |
| 4 | HD reverse camera | ||
| Storage battery | 1 | Type | Lead acid maintenance free (optional with lithium battery) |
| 2 | Battery capacity | Standard 48V-150AH*6/200AH*8/240AH*8lead-acid battery | |
| Electrical machinery | 1 | Walking motor | 1000W intelligent gear change |
| 2 | Rolling brush motor | 1000W | |
| 3 | side-brush motor | 4*100W | |
| 4 | Motor voltage | 48V | |
| High pressure water pump | 1 | High pressure fog-cannon range | 6-10m |
| 2 | High pressure water-gun range | 10-18m | |
| 3 | power | 1500W | |
| 4 | Pressure range | 0-13Mpa | |
| 5 | Max rate of flow | 11L/min | |
| Rearview mirror | 1 | model | Dedicated for sweeping vehicles |
