| Brand Name: | Bioclean |
| Model Number: | ZBJ5257GSSF3 |
| MOQ: | 1 |
| Price: | 15999 USD |
| Payment Terms: | T/T |
| Supply Ability: | 100unit/year |
| Specification | Details |
|---|---|
| Model Number | ZBJ5257GSSF3 |
| Volume | 10001 - 15000L |
| Certification | ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE |
| Emission Standard | Euro 6 |
| Sprinkling Area | 10-16m |
| Transmission Type | Manual |
| Payload | 13230kg |
| Fuel | Diesel |
| Drive Wheel | 6×4 |
| Engine Capacity | ＜4L |
| Condition | New |
| Chassis | ZZ1257N464GF1 |
| Engine | WP8.350E61 |
| Maximum Speed | 110km/H |
| Approaching/Departure Angle | 19°/15° |
| Wheelbase | 3200+1350mm |
| Front/Rear Overhang | 1430/2670mm |
| Curb Weight | 11640kg |
| Rated Loading | 13230kg |
| Total Mass | 25000kg |
| Tank Material | Carbon Steel or Stainless Steel |
| Tank Thickness | 4mm/5mm/6mm |
| Effective Volume | 13m³ |
| Transport Package | Wooden Case / Iron Frame / Container / SKD / CKD |
| Specification | 9300×2500×3050mm |
| Trademark | Bioclean |
| Origin | Ningbo, China |
| HS Code | 8705909990 |
| Production Capacity | 5000PCS/Year |
| Package Size | 950.00cm × 270.00cm × 320.00cm |
| Package Gross Weight | 12000.000kg |
| Serial Number | Component Name | English Description |
|---|---|---|
| 1 | Chassis | Adopt a second-class chassis of a well-known brand, which has strong load-bearing capacity, advanced technology and reliable quality. Engine: Adopt a diesel engine of a well-known brand, which has strong power. |
| 2 | Water Tank | The water tank has a large volume and a long working time. The water tank is optimized in design using the finite element analysis method and has passed strict reliability tests. The water tank adopts the advanced one-time tank forming technology, and it has been detected by penetration non-destructive flaw detection, with no water leakage and a long service life. |
| 3 | Low-pressure Water Circuit System | Low-pressure Water Pump: Adopt a self-priming two-stage centrifugal pump from a renowned enterprise. Front Spraying Device: Duckbill-shaped forward nozzles under the front of the cab. Middle Opposite Flushing: Conical nozzles on each side for two-way flushing. Rear Sprinkling Device: Duckbill-shaped nozzles on both sides with sprinkling width ≥14m. Water Cannon: Aluminum-made long-range water cannon with 50m range and 360° rotation. |
| 4 | Operation Mode | The vehicle adopts the control mode of "electric control pneumatic valve/solenoid valve". When starting and stopping the operation, the opening and closing of all nozzles except the water cannon are controlled through the operation box. |
