| Brand Name: | Bioclean |
| Model Number: | ZBJ5030TYHBEV |
| MOQ: | 1pc |
| Price: | Negotiation |
| Payment Terms: | T/T |
| Component | Description |
| Chassis | The chassis SC1031XND64A is manufactured by Changan Automobile Co., Ltd. in Chongqing. It features excellent power, safety and reliability. Engine:The DAM16KR National VI gasoline engine produced by Harbin Dongan Engine Co., Ltd. is adopted. The rated power is 90kW, and the displacement is 1597ml. |
| Carriage | An integrated carriage is used. A stainless steel water tank is installed at the front of the carriage, and the rear part is the operation compartment. |
| Front - end Working Device | The front - end working device is composed of a cleaning rack and a spot - spray device. The long - strip - shaped cleaning rack is equipped with nearly ten high - pressure nozzles. These nozzles can perform high - pressure cleaning on the road surface in rows, spraying water downwards. Moreover, driven by the air cylinder, the cleaning rack can swing up and down, as well as left and right, enabling comprehensive and flexible cleaning of the road surface. The spot - spray device features a single high - pressure nozzle, which has a long spraying range. The nozzle can move up and down, and it swings left and right under the drive of the cleaning rack, thus achieving precise spot - cleaning. |
| Rear - end Working Device | Inside the rear operation compartment, a gasoline water pump is installed as the cleaning drive mechanism, providing the necessary power for water spraying. Additionally, a winch and a handheld high - pressure water gun are also equipped. The handheld high - pressure water gun can be used by operators to flush sidewalks or water greenery in the surrounding areas, offering great flexibility in different cleaning and maintenance tasks. |
| Operating System | The operating system is located within the cab and is an integrated console. It allows for independent opening and closing of the cleaning rack and the spot - spray device. Operators can also control the left - right and up - down movements of these devices through the console, ensuring convenient and precise operation during cleaning tasks. |
