Product descriptions

•





  6m³ Mobile Waste Compaction Unit: High-Efficiency & Cost-Smart Sanitation Solution




  Tailored for small towns, suburban communities, remote residential areas, and micro-industrial parks in BRI nations, this 6m³ mobile compactor combines compact design with smart compression tech—meeting small-to-mid-scale waste management needs while prioritizing operational agility and long-term cost savings.




  Core Advantages: Efficiency & Economy




  Operational Efficiency




  • Optimized Throughput: 20-35 TPD, serving 15,000-40,000 residents or small industrial hubs. "Continuous compaction + quick bin exchange" boosts efficiency by 32% vs. 5m³ compactors.
  • Swift Compaction: Single high-pressure ram (100-140 tons force) completes a cycle in 110-150 seconds, ensuring non-stop processing during peak hours.
  • Smooth Loading: Sealed bins load onto light-duty trucks in ≤75 seconds, improving transfer efficiency by 23% vs. conventional small-capacity models.
  • Reliable Compression: 3.2:1 ratio (0.98 t/m³ density), reducing waste volume for small-scale operations.

  Cost Savings

  • Lower Transport Costs: 55% fewer truck trips vs. open bins, trimming annual fuel/labor/landfill costs by 26%.
  • Energy Efficiency: Streamlined hydraulic system uses 12-18 kW/h per cycle—15% lower than standard small-capacity compactors.
  • Minimal Maintenance: Wear-resistant components and simplified design extend intervals to 4 months, cutting annual upkeep by 19%.
  • Fast ROI: 3-4 year payback period, ideal for community projects, small property partnerships, and rural sanitation in emerging markets.

  Working Principle

  1. Waste Feeding: Compact auto-hopper (or optional manual conveyor) with smart anti-blockage mechanism ensures smooth flow of mixed waste—no manual intervention.
  2. Horizontal Compression: Single high-pressure ram exerts uniform pressure; adaptive control adjusts force by volume to balance efficiency and energy use.
  3. Sealed Transfer: Compacted waste is pushed into the 6m³ airtight bin with hydraulic locks. Quick-release latches enable fast truck loading for continuous operation.
  4. Eco-Friendly Operation: Compression sewage is collected in a closed tank (meets local discharge standards); activated carbon deodorization reduces odors, complying with BRI environmental regulations.
  5.


  Ideal Applications




  Small towns, suburban/residential areas, rural regions, small industrial parks, and BRI small-scale sanitation projects (e.g., Nepal, Cambodia, Uganda, Bulgaria)—replacing outdated open bins or low-efficiency small-capacity compactors in low-infrastructure areas.




  Why Choose This Model?




  A top small-scale solution for emerging markets, it balances compact size, efficiency, and cost-effectiveness. Its optimized compression ratio and swift cycle time maximize waste reduction, while the energy-saving system and simplified maintenance keep long-term costs low. Built with durable high-tensile steel to withstand varied climates and frequent use, it requires no professional training—making it ideal for municipal departments, small property operators, and rural sanitation partners, delivering consistent performance, tangible savings, and flexible deployment.




  Product Specification







  Parameter	Specification
  Rated Volume	6 m³
  Daily Processing Capacity	20-35 TPD
  Compression Ratio	3.2:1
  Compacted Waste Density	0.98 t/m³
  Compaction Force	100-140 tons
  Compression Cycle Time	110-150 seconds
  Energy Consumption per Cycle	12-18 kW/h
  Maintenance Interval	4 months
  Bin Loading Time	≤75 seconds/bin
  Overall Dimensions (L×W×H)	5200×2300×2500 mm
  Net Weight	3.2-3.8 tons
  Gross Weight (Full Load)	9-11 tons
  Main Structure Material	Q345B high-tensile steel (side plate: 4mm; base plate: 5mm)
  Feed Hopper Capacity	2.8 m³
  Hydraulic System Working Pressure	22 MPa
  Sewage Treatment	Closed-loop collection + simple filtration system
  Deodorization System	Activated carbon deodorization + natural ventilation
  Operating Temperature Range	-5℃ to 48℃
  Noise Level	≤74 dB
  Safety Standards	ISO 14121, CE certification
  Payback Period	3-4 years
