Horizontal Waste Compaction Station – High-Capacity, Continuous-Operation Sanitation Solution

Core Features

• High Throughput Capacity: Supports continuous operation for large-scale waste handling, ideal for daily volumes over 100 tons
• Horizontal Compression Design: Enables direct docking with 15–50 ton garbage trucks for efficient loading/unloading
• Modular Construction: Easy installation and expansion, adaptable to varying site sizes and waste volumes
• Durable & Low-Maintenance: Robust steel frame and wear-resistant components, reducing downtime by 30%
• Eco-Friendly Operation: Fully sealed compression chamber minimizes odor leakage and sewage overflow

•


  Working Principle

  1. Waste Feeding: Waste is directly loaded into the horizontal compression chamber via garbage trucks or conveyors, eliminating manual handling.
  2. Horizontal Compression: A hydraulic push plate compresses waste horizontally along the chamber, gradually forming dense waste blocks.
  3. Continuous Operation: As new waste is added, the push plate advances to compact existing waste, allowing non-stop feeding during compression.
  4. Waste Transfer: Compressed waste blocks are pushed into a sealed transport container or directly into a waste truck for off-site disposal.
  5. Environmental Control: Sewage is collected via a bottom drainage system, and an integrated deodorization unit reduces odor emissions to ≤20mg/m³.

  System Configuration

  • Main Structure: Q355B high-strength steel frame with reinforced compression chamber (12mm thickness), resistant to impact and wear.
  • Hydraulic System: Industrial-grade piston pump and double-acting cylinders for stable, high-pressure output.
  • Control System: PLC with touchscreen interface, supporting automatic operation, remote monitoring, and fault diagnosis.
  • Safety Systems: Emergency stop buttons, pressure relief valves, and anti-jam sensors to ensure operator safety.
  • Optional Add-Ons: Automatic deodorization system, sewage treatment unit, and IoT data tracking module.

  Ideal Applications

  • Large municipal waste transfer stations (daily throughput >100 tons)
  • Industrial parks and manufacturing facilities with high waste generation
  • Logistics hubs and port areas with concentrated waste collection
  • Urban sanitation centers serving dense metropolitan areas

  Why Choose Our Horizontal Compaction Station?




  Designed for heavy-duty use, our station cuts transport costs by 40% through high-density compression and reduces labor needs with automated operation. Its modular design allows on-site customization, while compliance with international environmental standards (e.g., EU CE, China GB) ensures seamless integration into global waste management systems. With a service life of 10–15 years and low maintenance requirements, it delivers long-term value for large-scale sanitation projects.




  Product Specification







  Parameter	Typical Range	Remarks
  Compression Force	200–600kN (20–60 tons)	Optimized for bulky/industrial waste
  Daily Processing Capacity	80–500 tons/day	Small: 80–200t; Medium: 200–300t; Large: 300–500t
  Compression Ratio	2.5:1–3:1	Reduces waste volume by 60–70%
  Compressed Waste Density	0.7–0.9t/m³	Stable density for long-distance transport
  Hydraulic Working Pressure	20–30MPa	Ensures consistent compression force
  Power Rating	30–75kW	Variable frequency drive for energy savings
  Equipment Dimensions	12m×4m×3.5m (L×W×H)	Modular sections for flexible layout
  Compression Cycle Time	5–7 minutes/cycle	Fast operation for continuous throughput
  Loading Interface	Compatible with 15–50t waste trucks	Direct rear/side loading options
